Nanjing Makas Carbide Knives Co.,Ltd. produce Zund Z17 Blade,Zund Z17,Zund Blade,Zund,3910307,Zund 3910307, Zund Z17 drag blade, knife, knives
TC knife blade Z 17
cutting depth approx. 12 mm
no. 3910307
suitable for machine manufacturer: original blade no.
Comagrav
CombiPro
Dyss
Esko Kongsberg: ( T17, G42441220, 42441220, BLD-SF217, (i-217) )
iEcho: ( E17 )
Mécanuméric: ( 100610390 )
Zünd: Z17, 3910307
recommended materials:
Folding Carton, Magnetic foil, Canvas, Self-adhesive vinyls, Reflective vinyls, PVC Banner, Paper, Polyester fabric, Foam, Gasket materials
Zund Blade Z17 HTZ-17 compatible for Zund automated cutting machine
Description: Blade for cutting thin materials. The overcut is smaller, but the blade exerts more drag force than the HTZ-016. For best results, use as an oscillating blade.
Thickness: 0,63 mm.
Tools: EOT and POT.
Composition: HM - Hard Metal.
Materials: Magnetic material, Polycarbonate, Polyester film, Coating blanket, Paper; 100 - 400 g, Folding carton; 100 - 1500 g
Compatible Brand
Zund
Equivalent
Z17
Thickness
0.63 mm.
Max. cutting depth
11 mm
Pre-cut
0.47 x Tm
Post-cut
-
Composition
HM - Metal Duro
Tool
POT / EOT
Recommended materials
Canvas
Coating blanket
Folding carton
Gasket materials
Hard foam
Magnetic material
PVC banner
Paper
Polycarbonate
Polyester fabric
Reflective vinyls
Self-adhesive vinyls
Oscillating blade pointed
Blade for cutting thin materials. The overcut is smaller, but the blade exerts more drag force on the material than the Z16. For best results, use as an oscillating blade.
Folding Carton
Magnetic foil
Canvas
Self-adhesive vinyls
Reflective vinyls
PVC Banner
Paper
Polyester fabric
Foam board/Foam
Gasket materials
Zund Blades Z10(3910301), Zund Blades Z11(3910309),Zund Blades Z12,Zund Blades Z13,Zund Blades Z16(3910306), Zund Blades Z17(3910307),Zund Blades Z20(3910313),Zund Blades Z21(3910314),Zund Blades Z22(3910315), Zund Blades Z23(5005560),Zund Blades 26(3910317), Zund Blades Z28(3910318),Zund BladesZ29(3910319),Zund Blades Z30(3910330),Zund BladesZ31(3910331),Zund Blades Z33(3910333), Zund Blades Z34(3910334),Zund Blades Z35(4800071), Zund Blades Z41(3910323),Zund Blades Z42(3910324), Zund Blades Z42C(5203005),Zund Blades Z43(3910325), Zund Blades Z44(3910340), Zund Blades Z46(4800073), Zund Blades Z50(3910335),Zund Blades Z51(3910336), Zund Blades Z52(3910337),Zund Blades Z53, Zund Blades Z55,Zund Blades Z60(5201345), Zund Blades Z61(5201343), Zund Blades Z62(5002488), Zund Blades Z63(5002637), Zund Blades Z64(5002739), Zund Blades Z66(5200479), Zund Blades Z68(5204301), Zund Blades Z69(5204302), Zund Blades Z70(5005642),Zund Blades Z71(5006045), Zund Blades Z73, Zund Blades Z82, Zund Blades Z83
