G42447284

Knife blade with 8mm cylindrical shaft for use with the RM (RIgidMaterial) knife tool. Good blade for cutting in rigid materials such as different gasket materials, forex, and solid carton board. 2 times 40 degrees angle.

Similar to DR8160. The blunter angle reduces the risk for breaking the blade in tough materials, but gives more overcut with thicker materials

Material	Sub Category	Thickness	Method
Adhesive (decal) vinyl	Adhesive (decal) vinyl	Standard thickness	Through
Corrugated	Microflute	Microflute	Static
Corrugated	Single Wall	F,E..(1-3mm) virgin	Static
Corrugated plastic	Corrugated plastic	< 5mm	Static
Flexible plastic sheet	Flexible plastic sheet	< 2mm	Static
Foamed PVC / PS	Foamed PVC / PS (Forex®, Sintra®)	< 5mm	Static
Folding carton	Folding carton	Folding carton	Static
Lenticular display panels	Lenticular display panels	< 5mm	Static
Magnetic foil	Magnetic foil	Magnetic foil	Static
Solid board	Display board	3mm	Static

D	Shank diameter	8mm
C	Maximum cutting thickness	5 mm - 3/16"

0.8 x 0.8 x 3.9 cm

0.02 kg
